Schütte WU 405 five-axis CNC universal tool and cutter grinder, built 1996 by Alfred H. Schütte, Cologne, Germany, with NUM CNC control and Siemens SIMODRIVE 611 drives. Travels X 540 / Y 280 / Z 260 mm, A/W rotary axis approx. 355°, C-axis grinding-head rotation 330°, manual grinding-head inclination ±25°, centre height approx. 200 mm, max. clamping length between centres approx. 700 mm, up to 999 divisions, programmable lead approx. 0.5 to 10,000 mm, grinding spindle approx. 1,800 to 12,000 rpm. Connection 400 V three-phase 50 Hz, 18 A. Weight approx. 3,150 kg. Location Germany, inspection possible.
available
Schütte WU405
| Manufacturer | Schütte |
| Model | WU 405 |
| Year | 1996 |
| Location | Germany |
| Manufacturer | Alfred H. Schütte, Cologne, Germany |
| Model | WU 405 |
| Year of manufacture | 1996 |
| Serial number | Series 12, No. 09 |
| Machine type | Five-axis CNC universal tool and cutter grinder |
| CNC control | NUM |
| Drive system | Siemens SIMODRIVE 611 |
| Axis travel | |
| - X axis | 540 mm |
| - Y axis | 280 mm |
| - Z axis | 260 mm |
| - A/W rotary axis | approximately 355° |
| - C-axis grinding-head rotation | 330° |
| - Manual grinding-head inclination | ±25° |
| Working range | |
| - Centre height | approximately 200 mm |
| - Maximum clamping length between centres | approximately 700 mm |
| - Maximum number of divisions | 999 |
| - Programmable lead range | approximately 0.5–10,000 mm |
| Feed ranges | |
| - X axis | 0.1–10,000 mm/min |
| - Y axis | 0.1–10,000 mm/min |
| - Z axis | 0.1–5,000 mm/min |
| Grinding spindle | |
| - Spindle-speed range | approximately 1,800–12,000 rpm |
| - Maximum spindle speed | 12,000 rpm |
| Electrical data | |
| - Rated operating voltage | 400 V |
| - Power supply | three-phase |
| - Frequency | 50 Hz |
| - Rated current | 18 A |
| - Electrical drawing number | PE-WU400-1209 |
| Approximate machine data | |
| - Machine weight | approximately 3,150 kg |
9,000 € · Inspection possible
